Tungsten electrodes
ATTL Advanced Materials Co., Ltd. is one of the most famous manufacturers of tungsten electrodes in China. It has been focusing its efforts on the development and production of tungsten electrodes for TIG welding since 1993. The abundant experiences in technology & production and the establishment of ISO9001:2008 quality control systems guarantee the excellent quality of the TLWM electrodes.
TLWM has an annual production capacity of 600 tons for all kinds of tungsten electrodes including Thoriated Tungsten, Ceriated Tungsten, Lanthanated Tungsten, Zirconiated Tungsten, Yttriated Tungsten and Pure Tungsten electrodes . Any kind and any size of tungsten electrode are available upon the demands from customers.
Length: 150mm, 175mm, 178mm and any other length at customer's request.
| Diameter of Electrode | DC(A) | AC(A) | |||
|---|---|---|---|---|---|
| in | mm | Straight Polarity(-) | Reverse Polarity(+) | Unbalanced Waves | Balanced Waves |
| 0.04" | 1.0 | 15-80 | 10-80 | 20-60 | |
| 1/16" | 1.6 | 60-150 | 10-18 | 50-120 | 40-100 |
| 0.079" | 2.0 | 100-200 | 12-20 | 70-160 | 60-130 |
| 3/32" | 2.4 | 150-250 | 15-25 | 80-200 | 80-150 |
| 1/8" | 3.2 | 220-350 | 20-35 | 150-270 | 120-200 |
| 5/32" | 4.0 | 350-500 | 35-50 | 220-350 | 170-260 |
| 3/16" | 4.8 | 420-650 | 45-65 | 240-420 | 220-340 |
| 1/4" | 6.4 | 600-900 | 65-100 | 360-560 | 250-450 |
